SMA-CZ01 vehicle mounted broadband self-organizing network radio is a high-power MESH product independently developed by our company.It can adopt multiple communication combinations and be applied to different usage scenarios.The radio can be installed on fixed base stations,as well as on mobile vehicles and ships.It can be turned on anytime and anywhere with just one click,making installation and operation simple without the need to configure or change parameters.This product is mainly used for long-distance construction of local communication and large-scale local networking.

　　Features+

　　● COFDM modulation with Efficient channel and multi-hop ADhoc network protocol technology;

　　● Strong function of anti complex environment;

　　● Self networking without station and high efficiency;

　　● All nodes can act as information acquisition node relay node or information output node at the same time;

　　● With IP interface,can be connected with other IP device.

　　Specifications+

　　● Frequency 570-590MHz/1428MHz~1448MHz（Customizable）

　　● Channel Bandwidth 5M，10M，20M

　　● Power 10W

　　● Transmission Rate 80Mbps

　　● WiFi 2.4G

　　● Sensitivity-93dBm 5MHz

　　● Working Temperature-20℃~+70℃

　　● Storage Temperature-40℃~+65℃
