1.Product Overview:
The SMA-VR01 Video Recovery Forensic System is a professional tool for forensics,recovery,and analysis of different types of videos.The supported video types include surveillance cameras,multimedia recorders,driving recorders,law enforcement recorders,drones,and other video formats.The video recovery forensics system adopts a unique algorithm for video recovery,which can thoroughly search and recover existing videos,deleted videos,and uncovered video fragments in the media.Even if the early recorded and saved videos in the medium have been covered by 99%,as long as there are residual videos that exist for a few seconds or even only one frame,they can still be completely restored.Simultaneously supporting queue based multitask scanning algorithms,adding multiple scanning tasks simultaneously,the system will automatically scan all added tasks without the need for manual waiting.The system also supports modules such as monitoring disk mirroring,video repair,video encoding conversion,and network recording extraction.
2.Main functional features:
1.Support embedded operating system file system parsing,file recovery,and intelligent data fragmentation reorganization.
2.Support file system scanning and extraction to quickly search for existing videos.
3.Support full disk scanning and extraction to quickly locate existing and lost videos.
4.Support area scanning and extraction,and quickly retrieve TB level monitoring hard drives.
5.Support remote extraction of network video recorders,directly connect to the internal network of the recorder through IP address and account information,and remotely view,download,search and other specified network video data of the recorder
6.Support automatic recognition of monitoring brand software
7.Supports over a hundred monitoring brand video formats
8.Support manual secondary identification of monitoring brands that cannot be automatically recognized
9.Support video format analysis function,use Hex display(hexadecimal)analysis view to deeply analyze video file formats.
10.Support fragment chart analysis view,display scan results in the form of block charts,color mark the clusters occupied by each video fragment,and view the overall data distribution of the disk
11.Support file location identification function,which can display the physical location and specific fragment composition area of the selected video file in a graphical manner.
12.Support video frame extraction technology,using the method of extracting static images to quickly view key video images and discover the required data(support AVI video recording).
13.Support video recovery for surveillance cameras,multimedia recorders,driving recorders,law enforcement recorders,and drones.
14.Support remote connection of network video recorders and remote online data extraction
15.Supports disk mirroring,may actively skip bad sectors to protect monitoring hard drives,supports DD and E01 image formats,and supports HASH calculation for images
16.Support video repair,batch repair of damaged and unplayable videos,and normal playback after repair
17.Support RecRepair and TruRepair dual video repair
18.Support manual addition and selection of third-party playback,no longer relying solely on one player
19.Support breakpoint continuation scanning,which can continue scanning at the last cancelled or stopped position,no longer causing scanning interruption due to human or accidental reasons,and then rescanning
20.Support IP log data extraction for monitoring video recorder login(supports Hikvision and Firestone monitoring)
21.Support screen recording,recording the entire video forensics process
22.Support the input of survey information:investigators,survey sites,survey records,and other information
23.Monitoring time correction:The system can calibrate the monitoring video time to ensure the accuracy of the occurrence time of the case
24.Support one click generation of on-site survey reports
25.Monitoring channel acquisition:can record the on-site monitoring probe to determine the point position,ensuring the accuracy of video orientation
