Product Overview
The SMILE4000 is a next-generation portable detection device based on ion mobility spectrometry. It features radiation-free operation, ultra-fast detection, high sensitivity, and low power consumption in a compact, lightweight, and easy-to-maintain design. Capable of detecting black powder, all ICAO-listed explosives, and drugs simultaneously, it is an ideal tool for security screening, counter-terrorism, and drug enforcement.
Applications
Security Screening: Ideal for airports, train stations, and other high-security locations.
Drug & Smuggling Enforcement: Used in national defense, customs, ports, and border inspections to detect drugs and contraband.
Public Safety: Ensures security at large events and safeguards public environments.
On-Site Investigation: Assists law enforcement and military personnel in detecting explosive residues at crime scenes.
Advantages
2.8" HD Touchscreen: Intuitive operation with a vibrant TFT display.
Dual Detection Modes: Easily switch between explosives and drug detection.
Fully Automated Analysis: No manual intervention required.
One-Touch Detection: Simple, user-friendly operation.
High-Precision Technology: Uses advanced ion mobility spectrometry for surface wipe and vacuum sampling.
Accurate Alerts: Audio and visual alarms identify specific hazardous substances.
Data Storage & Upgradeable Database: Saves detection records and supports real-time database updates.
Clear Visualization: Results displayed in an easy-to-read bar chart format.
Customizable Alarms: Adjustable thresholds for different security needs.
Auto Calibration & Self-Cleaning: Adapts to environmental changes and ensures continuous high performance.
Fast Results: Provides detection outcomes within 3 seconds.
Real-Time Diagnostics: Built-in troubleshooting and alerts for seamless operation.
Cost-Effective: Low-cost consumables and easy maintenance reduce operational expenses.
Specification:
General Specifications | |
Dimension | 470mm(W) × 170mm(L) × 197mm(H) |
Weight | 4.3KG |
Gross weight (kgs) | 15KG |
Packing size | 565*365*280mm |
Packing | Shork proof lining safe box |
Technical Specifications | |
Technology | Ion Mobility Spectrometry, IMS |
Radioactive source | No |
Explosives identify | Trinotrototuol(TNT), Hexogen(RDX), PETN, nitroglycerine, Ammonium nitrate(AN), Black Powder, Dinitrotoluene(DNT), Tetralite, Octogen(HMX), Nitroxanthic acid, Gena, C4, Semtex explosive, TPTA, HMTD, Nitroguanidine, HNS, Dinitroglycol |
Narcotics indentify | All types of restricted and unlisted drugs |
Sampling | Wipe sampling, additional option air inlet sampling, by test paper strimp |
Databases | Open to user, can add new type drugs |
Alarm | Sound / Light |
Sensitivity | 100ng |
Detection limit | 200pg cocaine |
Identify speed | ≤ 2 seconds |
Warm-up time | <20 minutes |
False alarm rate | ≤ 1% |
Display | 2.8 TFT color touch screen |
Maximum consumption | < 150W |
Power | Input AC 110-240V/50-60Hz; Output DC 19V/10.5A |
Operating temperature | -20°C~60°C |
Humidity | 45% ~95% |
Battery | 14.8V/4400mAh, continual working time> 2h and back up time>12h |
