Product introduction:

　　The SMA-S300 Raman spectrometer has outstanding detection performance in the industry.It is currently a rare handheld substance identification device on the market that has ultra long standby time and provides complete cloud platform support.Its detection database contains over 10000 substances,with the main feature of being able to detect black gunpowder and heroin,as well as mixtures.It can detect 4 types of solid mixtures and 5 types of liquid mixtures.

　　Function features:

　　Raman spectroscopy: molecular structure,precise detection,no need for sample pretreatment,direct detection,easy operation.

　　Support component analysis and proportion reference for up to 5 types of mixtures.

　　Calculation time<10s,efficient and fast inspection.

　　High accuracy,false alarm rate<10%.

　　High fluorescence substance identification technology: Adopting the unique DeepSpec TM algorithm,achieving precise substance identification .Combined with highly sensitive hardware,algorithms are used to extract signals of substances hidden in fluorescence,accurately identifying high fluorescence substances such as heroin,ketamine,xanthan gum,cellulose,etc.

　　Lightweight and compact: Portable,compact,and lightweight.Size:182(length)x 88(width)x 30(height)mm,weight:approximately 500g.

　　Fast detection speed: integrated optical path,high throughput,high sensitivity.Millisecond feedback speed,can directly read detection reports on the device display screen.

　　Support cloud platform:cloud database,bidirectional encryption,secure and stable.The cloud database is continuously updated and open to all users for free.

　　Advantages of cloud services:

　　a.Complete permission management,good security,private data is only visible to authorized users themselves;

　　b.The operating software can be upgraded online,and the more it is used,the more stable and powerful it becomes;

　　c.The model library is continuously updated,and the number of models continues to grow without limits;

　　d.Custom model cloud distribution,wireless synchronization between multiple devices;

　　e.The test records can be uploaded at any time,making it easy for colleagues from other places to view them in real-time;

　　f.Test result statistics,data analysis report presentation.

　　Technical parameter:

　　Data transmission: WiFi,4G

　　Interaction: Android based intelligent terminals

　　Touch screen: 1080P high-definition capacitive touch screen

　　Physical buttons: one click test

　　Camera: 13 million pixels,supporting download of original clarity images

　　Geographic information: Supports GPS,Beidou,and WiFi/4G network positioning

　　Working distance: pull-out damping probe,no need for fixed focus cap,continuously adjustable working distance

　　Working temperature: 0~40℃

　　Battery: replaceable polymer lithium battery;Battery life≥24 hours

　　Size: 182mm x 88mm x 30mm

　　Weight: approximately 500g
