Product introduction:
A new domesticated Nonlinear Junction Detector can detect any electronic devices hidden in walls,floors,ceilings,lamps,furniture or containers,regardless of whether these electronic devices are transmitting signals or not,and whether they are on or not,it can be alerted in various ways,such as through displays,vibration and sound prompts,so that the detectors can focus on the hidden targets.
Technical principle:
The Nonlinear Junction Detector(NLJD)antenna head is a transceiver(transmitter and receiver)that radiates a digital spread spectrum signal to determine the presence of electronic components.When the energy encounters semi-conductor junctions(diodes,transistors,circuit board connections,etc.),a harmonic signal returns to the receiver.The receiver measures the strength of the harmonic signal and distinguishes between 2nd or 3rd harmonics.When a stronger 2nd harmonic is represented on the display in red,it indicates an electronic junction has been detected.
Application:
It can be widely used in government,public security,prisons,justice,commercial security and personal privacy protection,etc.
Corporate trade secret protection:detecting unauthorized electronic devices hidden in important meeting rooms or confidential offices of the company,such as bugs,cell phones and SIM card-containing devices;
Explosive discharge for public security special police:detecting electronic explosive devices and remote controls in dangerous areas;
Personal privacy protection:hidden in homes,hotels and other places of clandestine photography and recording devices,such as voice recorders,cameras and so on.
Features:
High positioning accuracy
Adopting 2400MHz RF detection technology,featuring high-precision localization.
Good identification skills
Built-in spectrometer supporting second and third harmonic detection quickly and efficiently identifies semiconductor-containing devices and equipment,regardless of whether the device is powered on or off.
Highly penetrating
With the ability to penetrate the bullet layer of 370mm brick wall,there is no place to hide the steganography equipment.
High sensitivity
Especially for SIM card devices with high sensitivity,to ensure that the secret recording equipment,cell phone communication devices can be quickly detected.
Low false alarm rate
Built-in non-destructive detection algorithms dramatically improve detection capabilities with very low false alarm rates.
Harmlessness
Equipment to meet HJ/T10.2 radiation environmental protection requirements,safe and harmless to the human body.
Flexible and easy to operate
Simple and intuitive interface,fewer and more concise buttons,easy to operate manually.
Specification:
Parameters | Technical Specifications |
Operating Frequency Band | 2.4GHz |
Operating Voltage | 7.4V |
Frequency Range | 2.404GHz~2.472GHz |
Received 2nd~3rd Harmonic Range | 4.808GHz~4.944GHz, 7.212GHz~7.416GHz [Manual control (1MHz step adjustable), software automatic control] |
Pulse mode Transmitting Power (max) | 0~4W(EIRP) Power adjustable (manual control, automatic control) |
Reception Sensitivity | ≤-140dBm |
Adjustable range of transmission power | 0.05~1W |
Received Dynamic | 30dB |
Battery Operating Time(pulse mode, max power) | 2H |
Battery type | Replaceable lithium battery |
Charging Time | 2.5h/battery (fast charging) |
Operation Interface | LCD display of received harmonic signal strength; Supporting audio alert with headphones; Supporting vibration alert; |
Detection Distance | GPS module:400-500mm; Cellphone:180-220mm; SIM card:90-120mm; |
Working temperature | -20℃~45℃ |
Working Humidity | ≤85%, no condensate |
Product dimension | 548(L)× 170(W) × 113mm(H) |
Package Size | 625(L)× 445(W) ×230mm(H) |
Product weight | 1.6kg |
